Automatic mechanical self-locking.
The self-aligning steel jacking module can save time, improve the anti-sideload, no need wooden support stack material.
Operation process simplification, 50% less than the normal climbing jacking system, more efficiently.
Automatic mechanical self-locking.
The self-aligning steel jacking module can save time, improve the anti-sideload, no need wooden support stack material.
Operation process simplification, 50% less than the normal climbing jacking system, more efficiently.
An adjustable rotating saddle on the top to adjust the stroke 50mm.
494mm low collapsed height,max stroke 2067mm.
|
Model No. |
Max Side Load (m) |
Jacking Capacity per Unit (t) |
Stroke
(mm) |
Adjustable Saddle Stroke (mm) |
Max Oil Flow Rate (l/min) |
Forward
(cm³) |
Backward
(cm³) |
Block Weight
(kg) |
Base Weight
(kg) |
Block Weight
(kg) |
|
KET-JAD-108 |
1.5% @ 2m |
50 |
156 |
50 |
0.90 |
1225 |
624 |
40 |
360 |
16 |
|
KET-JAD-208A |
1.5% @ 2m |
100 |
156 |
50 |
1.12 |
2071 |
965 |
100 |
820 |
23.5 |
|
Model No. |
Mini Height with Block (mm) |
Max Height (mm |
A
(mm) |
B
(mm) |
C
(mm) |
D
(mm) |
E
(mm) |
F
(mm) |
G
(mm) |
H
(mm) |
I
(mm) |
J
(mm) |
K
(mm) |
L
(mm) |
M
(mm) |
N
(mm) |
P min. (mm) |
P max. (mm) |
|
KET-JAD-108 |
494 |
2067 |
494 |
2067 |
476 |
356 |
505 |
443 |
556 |
428 |
91 |
75 |
726 |
351 |
300 |
310 |
175 |
225 |
 |
 |
 |
 |
