Product Description:
1. Unique ”Safety Cage” system, can firmly fixed the work-piece with the good skid-resistance and safety.
2. Self – centering, anti – eccentric load, ensures that the screw rod is always in the center of force and extends the service life.
3. Through the T type handle and the safety cage to control the wheel quickly, it’s more convenient to operate.
4. Slim tapered jaws make it easier to work in narrow space.
5. NPT 3/8” quick coupling, can work with kinds of 700bar/10000psi power pack together.
6. Slim tapered jaws make it easier to work in narrow space.
Product Description:
1. Unique ”Safety Cage” system, can firmly fixed the work-piece with the good skid-resistance and safety.
2. Self – centering, anti – eccentric load, ensures that the screw rod is always in the center of force and extends the service life.
3. Through the T type handle and the safety cage to control the wheel quickly, it’s more convenient to operate.
4. Slim tapered jaws make it easier to work in narrow space.
5. NPT 3/8” quick coupling, can work with kinds of 700bar/10000psi power pack together.
6. Slim tapered jaws make it easier to work in narrow space.
| Model | Number of Jaws | Capacity(T) | Spread(min.-max.)(mm) | Max.reach(mm) | Cylinder Stroke（mm） | Oil capacity（cm3） | Weight （kg） |
| KET-EPH-106 | 3 | 5 | 178 | 152 | 127 | 83 | 7.5 |
| KET-EPH-108 | 3 | 10 | 304 | 203 | 156 | 226 | 11 |
| KET-EPH-110 | 3 | 15 | 381 | 245 | 254 | 516 | 23 |
| KET-EPH-113 | 3 | 25 | 457 | 304 | 362 | 1202 | 48 |
| KET-EPH-116 | 3 | 50 | 635 | 355 | 337 | 2399 | 91 |
| KET-EPH-206 | 2 | 5 | 178 | 152 | 127 | 83 | 7 |
| KET-EPH-208 | 2 | 10 | 304 | 203 | 156 | 226 | 10 |
| KET-EPH-210 | 2 | 15 | 381 | 245 | 254 | 516 | 22 |
| KET-EPH-213 | 2 | 25 | 457 | 304 | 362 | 1202 | 44 |
| KET-EPH-216 | 2 | 50 | 635 | 355 | 337 | 2399 | 87 |
 |
 |
 |
|
Cam disassembly
|
Disassembly of side wheel from large gearbox |
Bearing gear removal
|
